HIGH SPEED INTEGRATED MACHINING CENTER

Item	Unit	JF-T1600	JF-T2000	JF-V1600	JF-V2000
X/Y/Z Travel	mm	1600/600/450	2000/600/450	1600/600/600	2000/600/600
Spindle Center to Table	mm	150-600	150-600	150-600	150-600
Worktable Dimension (L*W)	mm	1700*600	2100*600	1700*600	2100*600
Max. Load	Kg	600	600	600	600
Spindle Taper	No.	BBT30	BBT30	BBT40	BBT40
Spindle RPM	r/min	20000	20000	12000	12000
Spindle Motor	kW	5.5	5.5	11 (Mitsubishi)	11 (Mitsubishi)
X/Y/Z Rapid Traverse	m/min	48/48/36	48/48/36	48/48/36	48/48/36
Tool Capacity	T	21	21	24	24

For more details refer to catalog

● This series of machines is an automated composite machining center that integrates milling, drilling, tapping and chamfering.
● Suitable for metal processing of various lengths of steel, copper, aluminum and other materials.
